Accuracy Report (ft)

LiDAR Accuracy

Date: 2025-10-10 04:56:44
Project Date: 2021-06-11 09:29:59
Location 37.790716, -122.311251
Powered by

Overview

This accuracy report describes the relationship between the ground control points and the LiDAR data. Each GCP is placed on the LiDAR data and a Z deviation is determined. The RMS takes into account the roughness of the LiDAR data to give a higher weight to GCP points on smoother surfaces.

Project Description

Rock R2A flown over airport

Horizontal Projection:
NAD83(2011) / California zone 3 (ftUS)
EPSG:
6420
Unit:
ft
NAD83(2011) / California zone 3 (ftUS) (3316)
Vertical Projection:
NAVD88 height (ftUS)
EPSG:
6360
Unit:
ft
NAVD88 height (ftUS) (6390)

View the data: Click here or go to https://cloud.rockrobotic.com/project/1802.

GCP Accuracy Summary

Point Density
57 points per sq ft
Vertical Accuracy
RMS
0.046 ft
Coverage
48 Acres
Standard Deviation
Elevation Delta
0.046 ft
Mean delta
in elevation
0.001 ft

Ground Control Points

GCP Name X Y Z-GCP (ft) Z-LiDAR (ft) Delta-Z (ft) Disabled
1 6039578.682 2115438.794 11.122 11.123 -0.001 No
2 6039578.692 2115438.81 11.117 11.123 -0.006 No
3 6039578.414 2115458.333 11.245 11.285 -0.04 No
4 6039587.87 2115453.915 11.237 11.229 0.008 No
5 6039588.191 2115444.826 11.101 11.153 -0.052 No
6 6039593.894 2115443.943 11.071 11.142 -0.071 No
7 6039594.047 2115438.941 11.044 11.169 -0.125 No
8 6039596.778 2115454.074 11.195 11.273 -0.078 No
9 6039596.769 2115458.56 11.231 11.31 -0.079 No
10 6039620.556 2115443.955 11.117 11.13 -0.013 No
11 6039621.684 2115439.168 11.084 11.145 -0.061 No
12 6039628.683 2115443.854 11.109 11.159 -0.05 No
13 6039628.489 2115458.796 11.229 11.23 -0.001 No
14 6039637.836 2115458.865 11.187 11.274 -0.087 No
15 6039638.213 2115439.256 11.063 11.1 -0.037 No
16 6039637.7 2115475.058 11.247 11.222 0.025 No
17 6039628.27 2115475.044 11.242 11.291 -0.049 No
18 6039627.858 2115489.929 11.108 11.124 -0.016 No
19 6039637.505 2115494.966 11.076 11.091 -0.015 No
20 6039637.495 2115495.006 11.07 11.087 -0.017 No
21 6039606.139 2115490.042 11.123 11.148 -0.025 No
22 6039606.135 2115475.007 11.268 11.264 0.004 No
23 6039596.725 2115479.767 11.213 11.25 -0.037 No
24 6039596.171 2115494.848 11.07 11.078 -0.008 No
25 6039587.33 2115494.971 11.035 11.077 -0.042 No
26 6039587.595 2115479.702 11.203 11.213 -0.01 No
27 6039578.314 2115474.868 11.227 11.257 -0.03 No
28 6039578.189 2115494.751 10.972 11.083 -0.111 No
29 6039537.124 2115468.09 11.177 11.232 -0.055 No
30 6039537.388 2115465.193 11.168 11.339 -0.171 No
31 6039502.252 2115464 11.124 11.13 -0.006 No
32 6039415.829 2115465.05 11.143 11.224 -0.081 No
33 6039415.788 2115467.949 11.183 11.251 -0.068 No
34 6039380.693 2115463.727 11.139 11.128 0.011 No
35 6039380.636 2115464.074 11.147 11.128 0.019 No
36 6039378.816 2115464.065 11.148 11.127 0.021 No
37 6039378.491 2115464.077 11.148 11.125 0.023 No
38 6039376.107 2115464.084 11.16 11.184 -0.024 No
39 6039376.108 2115463.791 11.159 11.193 -0.034 No
40 6039325.651 2115513.486 10.702 10.725 -0.023 No
41 6039325.537 2115519.463 10.657 10.638 0.019 No
42 6039326.601 2115520.539 10.643 10.664 -0.021 No
43 6039326.537 2115523.447 10.632 10.624 0.008 No
44 6039325.475 2115524.473 10.606 10.667 -0.061 No
45 6039325.35 2115530.38 10.565 10.561 0.004 No
46 6039326.461 2115531.843 10.564 10.541 0.023 No
47 6039300.612 2115524.391 10.623 10.648 -0.025 No
48 6039281.493 2115531.445 10.591 10.58 0.011 No
49 6039303.078 2115372.139 10.043 10.02 0.023 No
50 6039304.056 2115371.11 10.033 10.003 0.03 No
51 6039306.623 2115368.263 9.99 9.962 0.028 No
52 6039307.504 2115367.147 9.957 9.953 0.004 No
53 6039458.337 2115371.408 10.356 10.381 -0.025 No
54 6039460.266 2115371.416 10.357 10.332 0.025 No
55 6039459.644 2115372.506 10.351 10.424 -0.073 No
56 6039462.217 2115367.35 10.309 10.321 -0.012 No
57 6039461.96 2115368.523 10.316 10.328 -0.012 No
58 6039499.018 2115371.496 10.394 10.386 0.008 No
59 6039498.998 2115368.557 10.368 10.364 0.004 No
60 6039499.284 2115368.576 10.356 10.358 -0.002 No
61 6039499.334 2115371.531 10.401 10.41 -0.009 No
62 6039499.319 2115372.563 10.413 10.428 -0.015 No
63 6039499.042 2115372.53 10.405 10.428 -0.023 No
64 6039572.528 2115379.051 10.551 10.576 -0.025 No
65 6039572.581 2115391.475 10.677 10.665 0.012 No
66 6039572.487 2115403.997 10.808 10.788 0.02 No
67 6039572.443 2115416.666 10.877 10.881 -0.004 No
68 6039572.365 2115429.089 11 10.988 0.012 No
69 6039572.4 2115441.624 11.141 11.118 0.023 No
70 6039572.335 2115454.233 11.223 11.242 -0.019 No
71 6039572.281 2115466.727 11.312 11.312 0 No
72 6039572.158 2115479.072 11.208 11.221 -0.013 No
73 6039572.145 2115491.656 11.054 11.075 -0.021 No
74 6039572.182 2115504.253 10.897 10.914 -0.017 No
75 6039572.171 2115516.776 10.735 10.725 0.01 No
76 6039572.064 2115529.418 10.663 10.66 0.003 No
77 6039572.05 2115541.86 10.66 10.635 0.025 No
78 6039571.971 2115554.369 10.654 10.672 -0.018 No
79 6039586.994 2115554.4 10.645 10.618 0.027 No
80 6039602.053 2115554.415 10.64 10.604 0.036 No
81 6039616.983 2115554.451 10.668 10.642 0.026 No
82 6039632.017 2115554.495 10.642 10.6 0.042 No
83 6039647.035 2115554.535 10.602 10.596 0.006 No
84 6039662.006 2115554.583 10.578 10.542 0.036 No
85 6039678.068 2115546.67 10.577 10.604 -0.027 No
86 6039678.045 2115535.35 10.639 10.683 -0.044 No
87 6039677.948 2115531.77 10.678 10.757 -0.079 No
88 6039677.969 2115519.911 10.791 10.822 -0.031 No
89 6039677.899 2115516.69 10.834 10.819 0.015 No
90 6039678.156 2115505.264 10.974 10.967 0.007 No
91 6039678.045 2115501.863 11.014 11.017 -0.003 No
92 6039678.112 2115490.529 11.112 11.154 -0.042 No
93 6039678.136 2115486.837 11.157 11.185 -0.028 No
94 6039678.02 2115474.954 11.265 11.239 0.026 No
95 6039678.072 2115458.789 11.278 11.28 -0.002 No
96 6039678.157 2115447.265 11.209 11.173 0.036 No
97 6039678.454 2115443.775 11.177 11.151 0.026 No
98 6039678.45 2115432.349 11.069 11.105 -0.036 No
99 6039678.553 2115429.109 11.025 11.04 -0.015 No
100 6039678.268 2115417.208 10.888 10.833 0.055 No
101 6039678.199 2115413.914 10.908 10.815 0.093 No
102 6039678.165 2115402.209 10.855 10.752 0.103 No
103 6039678.273 2115398.842 10.827 10.784 0.043 No
104 6039678.391 2115387.349 10.731 10.668 0.063 No
105 6039828.213 2115386.648 10.849 10.808 0.041 No
106 6039827.198 2115399.204 10.896 10.877 0.019 No
107 6039827.302 2115387.503 10.811 10.807 0.004 No
108 6039827.188 2115402.713 10.921 10.885 0.036 No
109 6039827.066 2115414.288 10.926 10.867 0.059 No
110 6039827.099 2115417.766 10.946 10.897 0.049 No
111 6039826.997 2115429.19 11.057 11.033 0.024 No
112 6039827.004 2115432.789 11.079 11.059 0.02 No
113 6039827.025 2115444.574 11.22 11.175 0.045 No
114 6039827.045 2115447.897 11.25 11.231 0.019 No
115 6039826.972 2115458.864 11.443 11.379 0.064 No
116 6039826.86 2115475.393 11.479 11.442 0.037 No
117 6039826.793 2115487.152 11.399 11.347 0.052 No
118 6039826.75 2115490.84 11.347 11.29 0.057 No
119 6039826.731 2115502.319 11.175 11.118 0.057 No
120 6039826.794 2115505.503 11.113 11.092 0.021 No
121 6039826.811 2115517.248 10.872 10.848 0.024 No
122 6039826.842 2115520.691 10.823 10.779 0.044 No
123 6039826.796 2115532.318 10.657 10.687 -0.03 No
124 6039826.82 2115535.456 10.602 10.62 -0.018 No
125 6039826.856 2115546.907 10.526 10.396 0.13 No
126 6039847.828 2115562.546 10.502 10.379 0.123 No
127 6039847.839 2115565.46 10.453 10.389 0.064 No
128 6039616.717 2115452.058 11.305 11.24 0.065 No
129 6039616.666 2115452.584 11.299 11.228 0.071 No
130 6039616.661 2115452.761 11.303 11.228 0.075 No
131 6039616.684 2115453.314 11.304 11.24 0.064 No
132 6039616.646 2115453.777 11.302 11.255 0.047 No
133 6039616.604 2115454.264 11.311 11.272 0.039 No
134 6039616.64 2115455.006 11.315 11.288 0.027 No
135 6039617.073 2115455.007 11.312 11.281 0.031 No
136 6039617.556 2115454.986 11.297 11.27 0.027 No
137 6039618.04 2115454.975 11.309 11.264 0.045 No
138 6039618.634 2115455.008 11.3 11.27 0.03 No
139 6039619.082 2115454.984 11.311 11.256 0.055 No
140 6039619.09 2115454.484 11.31 11.245 0.065 No
141 6039619.071 2115454.277 11.325 11.245 0.08 No
142 6039619.045 2115453.771 11.327 11.232 0.095 No
143 6039619.104 2115453.318 11.311 11.219 0.092 No
144 6039619.089 2115452.841 11.316 11.219 0.097 No
145 6039619.116 2115452.108 11.293 11.221 0.072 No
146 6039153.162 2115229.567 7.407 7.467 -0.06 Yes
147 6039139.063 2115227.391 7.477 8.106 -0.629 Yes
148 6039131.349 2115224.087 7.387 7.892 -0.505 Yes
149 6039121.64 2115232.244 7.462 8.082 -0.62 Yes
150 6039095.737 2115234.038 7.416 7.514 -0.098 Yes
151 6039080.805 2115238.491 7.516 8.567 -1.051 Yes
152 6039074.76 2115239.154 7.466 7.822 -0.356 Yes
153 6039054.764 2115243.986 7.561 8.433 -0.872 Yes
154 6039053.885 2115231.246 7.511 7.829 -0.318 Yes
155 6039035.55 2115239.31 7.582 7.879 -0.297 Yes
156 6039026.111 2115232.075 7.429 7.775 -0.346 Yes
157 6038847.115 2115365.589 8.866 8.918 -0.052 No
158 6038847.131 2115377.901 8.895 8.923 -0.028 No
159 6038847.198 2115390.27 9.094 9.111 -0.017 No
160 6038847.284 2115402.83 9.215 9.166 0.049 No
161 6038847.306 2115415.203 9.316 9.334 -0.018 No
162 6038847.04 2115427.632 9.469 9.441 0.028 No
163 6038847.128 2115440.165 9.657 9.695 -0.038 No
164 6038846.903 2115452.626 9.819 9.785 0.034 No
165 6038846.78 2115465.569 10.012 10.01 0.002 No
166 6038846.848 2115477.876 9.988 10.02 -0.032 No
167 6038847.046 2115490.357 9.972 9.981 -0.009 No
168 6038846.875 2115502.953 9.963 9.953 0.01 No
169 6038846.848 2115515.294 9.891 9.937 -0.046 No
170 6038846.837 2115527.918 9.923 9.987 -0.064 No
171 6038846.741 2115540.266 9.908 9.921 -0.013 No
172 6038846.734 2115552.787 9.864 9.883 -0.019 No
173 6038846.798 2115564.851 9.778 9.749 0.029 No
174 6038861.045 2115565.221 9.762 9.774 -0.012 No
175 6038896.261 2115565.447 9.864 9.864 0 No
176 6038911.104 2115565.484 9.898 9.967 -0.069 No
177 6038926.152 2115565.51 9.956 9.984 -0.028 No
178 6038941.24 2115565.491 9.977 9.996 -0.019 No
179 6038956.302 2115565.499 10.018 10.103 -0.085 No
180 6038971.206 2115565.538 10.014 10.033 -0.019 No
181 6038986.357 2115565.729 10.054 10.09 -0.036 No
182 6039001.377 2115565.749 10.095 10.113 -0.018 No
183 6039016.394 2115565.775 10.078 10.126 -0.048 No
184 6039046.369 2115565.81 10.051 10.086 -0.035 No
185 6039061.549 2115565.74 10.041 10.041 0 No
186 6039106.28 2115465.776 10.815 10.871 -0.056 No
187 6039120.204 2115465.877 10.865 10.856 0.009 No
188 6039136.508 2115466.108 10.877 10.86 0.017 No
189 6039151.43 2115465.983 10.903 10.92 -0.017 No
190 6039684.132 2115017.081 9.49 -999.0 1008.49 Yes
